App available WTRtec App →Highlights
- Chlorination in reservoirs of drinking water
- Chlorination in-line of drinking water
- Chlorination in cooling tower
- Controller for pH adjusting
- Controller for proportional fertilizer dosing and pH adjusting
- Contrôle de
pH, ORP, EC, chlore libre, dosage proportionnel
Information produit
WTRtec controllers allow the user to monitor free chlorine, pH, ORP (RedOx), conductivity, flow and temperature, as well as its regulation through the control outputs for metering pumps for water treatment and fertigation.
The configuration options allow control in-line through an analogue output (mA) with PI regulation.
WTRtec BLUE
Multi-parameter controller for adjusting free chlorine and pH in drinking water reservoirs, with ORP (Red-Ox) safety measurement.
WTRtec WHITE
Multi-parameter controller for adjusting free chlorine and pH in-line with ORP (Red-Ox) safety measurement.
WTRtec GREY
Multi-parameter controller for adjusting free chlorine, pH and electrical conductivity in cooling towers.
WTRtec RED
Controller for adjusting pH in the tank or in-line.
WTRtec GREEN
Multi-parameter controller for proportional fertilizer dosing and pH adjusting in-line
| Inputs | |||||
 |  |  |  |  |
|
| Cl 2: Sensor ITC | x | x | x | ||
| ORP (RedOx) | x | x | |||
| pH | x | x | x | x | x |
| Débit | x | x | x | x | x |
| EC | x | x | |||
| ºC-ºF | x | x | x | x | x |
| Détecteur de débit | x | x | x | x | x |
| Outputs | |||||
| | | | |
|
| Sortie doseuse Cl | x | x | x | ||
| Sortie doseuse pH | x | x | x | x | x |
| Sortie doseuse proportionnel | x | ||||
| Control PIQ Cl | x | ||||
| Control PIQ pH | x | x | x | ||
| Control PIQ EC | x | ||||
| Alarm Cl | x | x | x | ||
| Alarm ORP | x | x | |||
| Alarm pH | x | x | x | x | x |
| Alarm débit | x | x | x | ||
| Alarm EC | x | x | |||
ÉLECTRIQUE
Alimentation: 100-250VAC
Protection: IP65
Température: 0-45 ºC
POIDS ET DIMENSIONS
Manuels
- Brochure WTRtec
- Brochure fertigation WTRtec
- WTRtec BLUE/WHITE
- WTRtec GREY
- WTRtec RED
- WTRtec GREEN
- ModBus Manuel
Data Sheets
| Filename | EN | ES | |
| WTEC001 WTRtec Technical Features |  |  |
|
| WTEC002 Panel WTRtec | | |
|
| WTEC003 WTRtec Options for cables and connectors | | |
|
| WTEC004 WTRtec Blue Technical Features | | ||
| WTEC005 WTRtec WhiteTechnical Features | | ||
| WTEC006 WTRtec Grey Technical Features | | ||
| WTEC007 WTRtec Red Technical Features | | ||
| WTEC008 WTRtec Green Technical Features | | ||
| WTEC010 Panel WTRtec White | |
